Features:

• Nominal 25 gauge hot dipped galvanized steel construction with hemmed inside return rail.
• 1.0 mil paint system includes .25 mil rust inhibiting primer and .75 mil exterior top coat that resists fading and chalking while providing consistent color from panel to panel.
• 19 gauge hot dipped galvanized steel stiles include rolled safety edge.
• Stiles attached with rivets to provide superior strength when compared to common sheet metal joining methods
• Sections include tongue and groove meeting rails for superior strength and better sealing against wind, rain and snow.
• Rigid aluminum retainer provides added strength while securing replaceable u-shapped bottom weatherstrip.
• Model 511 is insulated (R value: 6.85) with CFC Free expanded polystyrene with a high impact plastic back cover

Door Widths Panels Wide Heights Available : 6'6", 6'9", 7'0", 7'6", 7'9", 8'0"

8', 9' 10' 12' 14', 15' 16', 17', 18'

Features:

• Nominal 25 gauge hot dipped galvanized steel construction with hemmed inside return rail.
• 1.0 mil paint system includes .25 mil rust inhibiting primer and .75 mil exterior top coat that resists fading and chalking while providing consistent color from panel to panel.
• 19 gauge hot dipped galvanized steel stiles include rolled safety edge.
• Stiles attached with rivets to provide superior strength when compared to common sheet metal joining methods
• Sections include tongue and groove meeting rails for superior strength and better sealing against wind, rain and snow.
• Rigid retainer provides added strength while securing replaceable u-shaped bottom weatherstrip.
• Model 591 is insulated (R value: 6.85) with CFC Free expanded polystyrene with a high impact plastic back cover

Sizes Available:

Door Widths Panels Wide Heights Available : 6'6", 6'9", 7'0", 7'6", 7'9", 8'0"

8', 9' 10' 12', 14' 15', 16', 17', 18'

Features:

• Sandwich type construction with CFC free expanded polystyrene insulated pressure bonded between two sheets of 26 gauge hot dipped galvanized steel with a 10.25 R value.
• 1.0 mil paint system includes .25 mil rust inhibiting primer and .75 mil exterior top coat that resists fading and chalking while providing consistent color from panel to panel.
• 20 gauge hot dipped galvanized steel hinge plates run the full height of each section at all hinge locations to facilitate the attachment of hinges, handles, struts and step plates.
• Interior has Pebble Grain Finish.
• Rigid aluminum retainer provides added strength while securing replaceable u-shaped bottom weatherstrip.
• Sections include tongue and groove meeting rails for superior strength and better sealing against wind, rain and snow

Door Widths Panels Wide Heights Available : 6'6", 6'9", 7'0", 7'6", 7'9", 8'0"

8', 9' 10' 12' 14', 15' 16', 17', 18' 20'

Features:

• Sandwich type construction with CFC free expanded polystyrene insulated pressure bonded between two sheets of 26 gauge hot dipped galvanized steel with a 10.25 R value.
• 1.0 mil paint system includes .25 mil rust inhibiting primer and .75 mil exterior top coat that resists fading and chalking while providing consistent color from panel to panel.
• 20 gauge hot dipped galvanized steel hinge plates run the full height of each section at all hinge locations to facilitate the attachment of hinges, handles, struts and step plates.
• Rigid aluminum retainer provides added strength while securing replaceable u-shapped bottom weatherstrip.
• doorLink™ designs are protected by US patent #D487521.
• Sections include tongue and groove meeting rails for superior strength and better sealing against wind, rain and snow.

Sizes Available:

Door Widths Grooved panels Heights Available : 6'6", 6'9", 7'0", 7'6", 7'9", 8'0"

8', 9', 10' 16', 17', 18'
